Description
Despite its compact dimensions, DB3D delivers astonishingly powerful, controlled bass thanks to its twin 8in Aerofoil™ drivers, 1000 watt amplifier and digital signal processing.
Power packed
DB3D’s tight, powerful and dramatic bass and compact size make it the perfect match for the 804 D3 and 805 D3 speakers.
The perfect match
DB3D’s ultra-rigid low-resistance enclosure comes in three finishes to match the 800 Series Diamond and 700 Series loudspeakers.
More bass, less space
Compact model packs a mighty punch. Controllable, dramatic bass from a subwoofer so small it fits almost anywhere: DB3D is a space-saving high-performance design.
Nimble and powerful
Solid, dramatic bass is delivered through the rigidity and lightness of the uniquely-shaped variable thickness Aerofoil™ cone.
A question of balance
The back-to-back (opposed) drivers cancel out cabinet resonances, ensuring all that power is used to create room-shaking bass, not wasted vibrations.
The digital advantage
Digital amplification is cool-running and energy efficient, even when working hard, while Dynamic EQ and Room EQ ensure a precise sound for music and movies.
Take control
By placing control in the palm of your hand, our subwoofer app not only makes our DB Series subwoofers a snap to set up, it also helps maximise your sound quality
| Description: | DB series subwoofer |
| Technical Features: | 1000w Class D Hypex amplifier 2 x 200mm (8in) Aerofoil™ cone drive units in a balanced configuration Digital preamplifier with Dynamic EQ App-based set-up and BT-LE control |
| Drive Units: | 2 x 200mm (8in) Aerofoil™ cone drive units in a balanced configuration |
| Frequency Range: | 8.5Hz – 500Hz |
| Frequency Response -3dB (centred on level at 100Hz): | 10Hz – 350Hz |
| Maximum Power Output: | 1000W |
| Inputs: | 2 x XLR 2 x RCA 2 x 3.5mm 12V trigger RS232 9-pin D connector |
| Dimensions: | Height: 360mm Width: 320mm Depth 300mm |
| Net weight: | 25kg |
| Colour: | Gloss Black |
| Manufacturer’s Warranty*: | 2 years |
