Ubiquiti UniFi PoE+ Adapter (U-POE-AT)

£22.50

Ubiquiti UniFi PoE+ Adapter (U-POE-AT)

The Ubiquiti UniFi U-POE-AT is an adapter that can power UniFi PoE+ devices with wireless mesh applications, or offload PoE switch power dependencies.

U-POE-at Key Features:

  • Delivers up to 30W of PoE+
  • Compatible with the U6 LR, U6 Pro, and other PoE+ devices
  • Surge, peak pulse, and overcurrent protection
  • AC cable with earth ground
  • LED indicator for status monitoring
Category: Tags: , , , , ,

Description



  • Ubiquiti U-POE-AT Technical Specifications
  • Model U-POE-at
  • Dimensions 93 x 62 x 35 mm (3.66 x 2.44 x 1.38″)
  • Weight 156 g (5.5 oz)
  • Output Voltage 48VDC @ 0.65A
  • LAN Activity Indicator No
  • Gigabit LAN Port Yes
  • Remote Reset Capability Yes
  • Reset Button No
  • Rated Voltage 100-240VAC @ 50/60Hz
  • Input Current 0.75A@90VAC
  • Inrush Current <100A Peak @230VAC, 26℃
  • Efficiency 87%
  • Output Ripple 1% Max.
  • Switching Frequency 70 kHz Max.
  • Line Regulation ≤ 3%
  • Load Regulation ≤ 5%
  • 2-Pair Powering Pins 4, 5 (+) and Pins 7, 8 (-)
  • 4-Pair Powering –
  • Operating Temperature 0 to 40° C (32 to 104° F)
  • Storage Temperature -30 to 70°C (-22 to 158° F)
  • Operating Humidity 35 to 90% Noncondensing
  • AC Connector IEC-320 C6

    If you’re looking for this product to be installed in your home, our specialist installation team can help. Contact us online or visit our showroom to chat.
