Model Year
Model Year: 2024
TV System
TV System (analog): B/G,D/K
Tuner Channel Coverage (analog): 45.25MHz-863.25MHz
(Depend on country selection)
TV System (Digital Terrestrial): DVB-T/T2
Tuner Channel Coverage (Digital Terrestrial): VHF/UHF(Depend on country selection)
TV System (Digital Cable): DVB-C
Tuner Channel Coverage (Digital Cable): VHF/UHF/cable(Depend on country selection)
TV System (Digital Sat): DVB-S/S2
Tuner Channel Coverage (Digital Sat): Intermediate Frequency 950-2150MHz
Number of Tuners (Terrestrial / Cable): 2(Digital)/1(Analog)
Number of Tuners (SAT): 2
Colour system: PAL/SECAM
CI+: Yes
Colour space: sRGB/BT709
BT2020
AdobeRGB
DCI
Operating system: Android 12
On-board storage: 32GB
Display Features
X-anti reflection: Yes
Display type: LCD
X-wide angle: Yes
Rich Colour Enhancer: N/A
Backlight dimming type: Local Dimming
Display Specs
Screen size (diagonal): 75" / 189cm
Backlight type: Mini LED (QLED)
Display resolution (pixels): 3840 x 2160
Viewing angle (right / left): 178(89/89) degree
Viewing angle (up / down): 178(89/89) degree
Display resolution: QFHD
Aspect ratio: 16:9
Video Features
XR Backlight Master Drive: Yes
Peak Luminance: XR Contrast Booster 30
TRILUMINOS: XR Triluminos Pro
Features for PlayStation®5 Auto HDR Tone Mapping: Yes
Features for PlayStation®5 Auto Genre Picture Mode: Yes
XR Clear Image: Yes
High Peak Luminance: Yes
Picture modes: Vivid
Standard
Cinema
Professional
Calm
IMAX Enhanced
Dolby Vision (Vivid/Bright/Dark/Game)
FPS game
RTS game
Auto Wide: Yes
Wide Mode: Full
Vertical Fit
Horizontal Fit
Original,Full
Vertical Fit
Horizontal Fit
Original
4:3 Default: –
Video Processing: –
Motion enhancer: XR Motion Clarity
Auto mode
Blinking Type: Line Blinking
Live Colour™ Technology: Yes
CineMotion/Film Mode/Cinema Drive: Yes
4K Processor: XR Processor
HDR (High Dynamic Range) compatiblity: HDR10
HLG
Dolby Vision
Panel Refresh Rate (Native Hertz): 120Hz
Dynamic Contrast Enhancer: Yes
Audio Specs
Channel: 2.2.2ch
Audio Power Output: 10W + 10W + 10W + 10W + 10W + 10W + 5W + 5W
(except in power saving mode)
Speaker Position: Front + Side + Top
Bass/Treble/Balance: Balance
Speaker Type: Acoustic Multi-Audio+
Speaker Configuration: Multi way Multi-amplifier connections
(Tweeter x 2, Mid Range x 2, Subwoofer x 2, Beam Tweeter x 2)
Digital audio out (Optical) format: Two channel linear PCM: 48kHz 16bits
Dolby Audio
DTS
Audio Features
Acoustic Center Sync: Yes (S-CENTER SPEAKER IN)
Ready for 360 Spatial Sound Personalizer: Yes (via Bluetooth)
Simultaneous Sound Output with TV Speaker: Bluetooth A2DP Device
Vertical Surround Engine: Vertical Surround Engine
Acoustic Auto Calibration: Room & User Position Compensation
Speaker Type-2: Frame Tweeter
Beam Tweeter
Clear Phase: Yes
S-Master: S-Master Digital Amplifier
Auto Surround: Yes
DTS audio format support: DTS Digital Surround
DTS Express
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS:X
Simulated surround sound: S-Force Front Surround
Dolby audio format support: Dolby Audio
Dolby Atmos
Voice Zoom: Voice Zoom 3
(Also available with compatible Sony Soundbar)
HDMI Audio Return Channel(ARC): Yes (eARC/ARC)
Advanced Auto Volume: Yes
Auto Mute (on no signal): Yes
HDMI input Audio format: 7.1 channel linear PCM: 32/44.1/48/88.2/96/176.4/192kHz 16/20/24bits
Dolby Audio
Dolby Atmos
DTS
DTS Express
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS:X
ARC output format: Two channel linear PCM: 48kHz 16bits
Dolby Audio
Dolby Atmos
DTS
Network Features
Control Menu: Yes
ECO Dashboard: Yes
USB Tethering: Yes
Apple AirPlay: –
Apple HomeKit: Yes
Home Network Feature: Home Network Client
Home Network Renderer
Wi-Fi Direct: –
Wi-Fi Certified: Yes
Screen mirroring(Miracast™): –
Video & TV SideView (iOS/Android): –
Wi-Fi Standard: a/b/g/n/ac/ax
Wi-Fi Frequency: 2.4GHz
5GHz
6GHz
Photo Sharing Plus / Photo Share: –
Internet Browser: Yes
Codec for Home Network: MPEG1:MPEG1
MPEG2PS:MPEG2
MPEG2TS(HDV,AVCHD):MPEG2,AVC
MP4(XAVC S):AVC,MPEG4,HEVC
AVI:Xvid,MotionJpeg
ASF(WMV):VC1
MOV:AVC,MPEG4,MotionJpeg
MKV:Xvid,AVC,MPEG4,VP8.HEVC
WEBM:VP8
3GPP:MPEG4,AVC
MP3
ASF(WMA)
LPCM
WAV
MP4AAC
FLAC
JPEG,WEBM:VP9
AC4
ogg
AAC
ARW(Screen nail only)
Wireless LAN: Integrated
Convenience Features
Optimization of HDMI input: Prioritize HDMI content type information
Source-Based Tone Mapping(SBTM): Yes(for HDMI3/4)
Function by Camera: –
UVC/UAC support: Yes
Multi-View: –
Variable Refresh Rate (VRR): Yes (for HDMI3/4)
Auto Low Latency Mode (ALLM): Yes (for HDMI1/2/3/4)
Features specified in HDMI2.1: 4K120
eARC
VRR
ALLM
SBTM(Source-Based Tone Mapping)
Built-in Mic switch: Yes(Left)
X-Protection PRO: Y (with Lightning, Surge, Humidity Protection)
Electronic Program Guide (EPG): Yes
USB HDD Recording: Yes(1Rec)(Except Italy)
USB playback codecs: MPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC,JPEG/HEIF/WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)
Built-in Mic: Yes
Text Input Language: ARA / BUL / CAT / HRV / CES / DAN / DUT / ENG / EST / FIN / FRA / GER / GRK / HEB / IND / ITA / JPN / NOR / FAS / POL / POR / RON / RUS / SLK / SLV / SPA
Chromecast built-in: Yes
Application Store: Yes (Google Play Store)
BRAVIA Sync (including HDMI-CEC): Yes
Control for HDMI (HDMI CEC): –
i-Manual: Yes
Parental Control: Yes
Channel Block (with password): Digital
Show/Hide Channels: –
On Screen Clock: Yes
Sleep Timer: Yes
On/Off Timer: Yes
USB drive format support: Yes (Supported File System: FAT16/FAT32/exFAT/NTFS)
Display Language: AFR,AMH,ARA,ASM,AZE,BEL,BUL,BEN,BOS,CAT,CZE,DAN,DEU,GRE,ENG,SPA,EST,BAQ,PER,FIN,FRA,GLG,GUJ,HIN,HRV,HUN,IND,ISL,ITA,HEB,JPN,KAZ,KAN,KOR,KIR,LAO,LIT,LAV,MAC,MAL,MON,MAR,MAY,BUR,NOB,NEP,NLD,ORI,PAN,POL,POR,RUM,RUS,SOL,SLV,ALB,SRP,SWE,SWA,TAM,TEL,THA,TGL,TUR,UKR,URD,UZB,VIE,zh_CN,zh_HK,zh_TW,ZUL
Auto Shut-off: –
Sensing Features
Sensor: Light
Colour
Energy Saving & Efficiency
SORPLAS: Yes
Wireless Network(s) On/Off Switch (Energy): –
On mode power 1000h SDR(New lot5): 83 kWh/1000h
Mercury content(mg): 0.0
Lead Content: Yes
Dynamic Backlight Control: Yes
Power Saving Mode / Back Light Off Mode: Yes
General Features
Smart TV: Google TV
SONY PICTURES CORE Calibrated mode: Yes
Prime Video Calibrated mode: Yes
(Firmware update may be required.)
Auto Calibration with CalMAN: Yes
Netflix Calibrated mode: Yes (Adaptive Calibrated Mode)
IMAX Certified Model: Yes
SONY PICTURES CORE: 10 credits/24 months
Demo Mode: Yes(e-POP only)
Accessibility Features
Color Inversion: Yes
Screen Reader: Yes
Audio Description: Yes
Closed Captions (Digital): Subtitle
Text Magnification: Yes
Accessibility Shortcut: Yes
Voice Search: Yes
Menu timeout settings: Yes
Power-on Volume settings: Yes
TalkBack: Yes
Switch Access: Yes
Broadcast Features
Teletext: Yes
Teletext number of pages: 1000 pages
Design Features
Stand Position: 4-way position (Outside/Inside/Ouside for Soundbar/Inside for Soundbar)
Stand Color: Dark silver/Hairline
Bezel Design: Seamless Edge
Cable Management: Yes
Frame color: Dark Silver/Vibration finish
Stand Design: Underlay stand
Inputs and Outputs
HDMI Signal: 4096x2160p(24,50,60Hz)
3840x2160p(24,25,30,50,60,100,120Hz)*3
1080p(24,30,50,60,100,120Hz)
1080i(50,60Hz)
720p(24,30,50,60Hz)
576p
480p
HDCP: HDCP2.3(for HDMI1/2/3/4)
Bluetooth profile support: Version 5.3,HID/HOGP/SPP/A2DP/AVRCP
4K 60P High-Quality formats: HDMI IN1, IN2 ports for 4K(up to 18Gbps) signal
HDMI IN3, IN4 port for 4K(up to 48Gbps) signal
AC Power Input: Pigtail (REAR)
RF (Terrestrial/Cable) Connection Input(s): 1(Side)
IF (Satellite) Input(s): 2(Side)
HDMI inputs total: 4(4Side)
Digital Audio Output(s): 1(Side / Hybrid with S-Center Speaker Input)
USB ports: 2(Side)
Ethernet inputs: 1(Side)
PCMCIA Slot(s): 1(Side)
HDMI PC Input Format: 640×480(31.5kHz,60Hz)
800×600(37.9kHz,60Hz)
1024×768(48.4kHz,60Hz)
1280×1024(64.0kHz,60Hz)
1152×864(67.5kHz,75Hz)
1600×900(55.9kHz,60Hz)
1680×1050(65.3kHz,60Hz)
1920×1080(67.5kHz,60Hz)
Power
Power consumption (Networked Standby Mode): 2.00W(Wi-Fi)
2.00W(LAN)
0.50W(CEC)
Power Requirements (voltage): 220 V – 240 V AC
Power Requirements (frequency): 50 Hz
Rated Power Consumption: 472 W
Power Consumption (Standby Mode): 0.50 W
Regulation and Standard Compliance
VESA® Hole Spacing Compatible: Yes
VESA® Hole Pitch(W x H): 30.0 x 30.0 cm
Measurements
TV with Stand (Inside for Soundbar) (W x H x D): Approx. 166.7 x 103.4 x 39.7 cm
TV with Stand (Standard position) (W x H x D): Approx. 166.7 x 97.2 x 39.7 cm
TV without Stand (W x H x D): Approx. 166.7 x 96.0 x 4.8 cm
TV with Stand (Soundbar position) (W x H x D): Approx. 166.7 x 103.4 x 39.7 cm
Dimension of Package Carton (W x H x D): Approx. 178.8 x 110.5 x 20.0 cm
Stand width (Standard position): Approx. 165.7 cm
Stand width (Narrow position): Approx. 54.3 cm
Stand width (Soundbar position): Approx. 165.7 cm
AC Cable Length: 1500mm
Weights
TV with Stand: Approx. 45 kg
Weight of TV without Stand: Approx. 42.3 kg
Weight of Package Carton(Gross): Approx. 56 kg
Supplied Accessories
Voice Remote Control (supply) included Rechargeable Battery: Yes
USB Type-C Cable: Yes
Voice Remote Control: RMF-TX920U
Remote Control: RMT-TX450E
Batteries: R03
AC Power Cord Spec: (Pig-tail43mm) (UK) (3pin) (flat blades)
Operating Instructions: EN,FR,ES,NL,DE,PT,IT,SE,DK,FI,NO,PL,CZ,SK,HU,RO,BG,GR,TR
Quick Setup Guide / Supplement CUE (GA): EN,FR,ES,NL,DE,PT,IT,DK,NO,SE,FI,PL,CZ,SK,HU,RO,BG,GR,TR,RU,UA,AR
Table Top Stand: Separate (Assembly required)
