Description
- High-performance patch cords that are individually tested
- Ultra-slim design with a 3.9mm cable diameter
- Composite nylon snap-proof latch
- Fully support IEEE802.3bt PoE++ 100W
- Kordz Lifetime Warranty
Kordz PRO SlimCat™ Patch Cords are a revolutionary solution for streamlined network installations that deliver all the power of Cat 6 cable in half the size. Engineered for Cat 6 1Gbps performance over 28AWG conductors, together with small profile nylon composite connectors, these ultra-slim patch cords redefine the possibilities of cable management while delivering certifiable performance. PRO SlimCat™ Patch Cords feature a unique composite nylon snap-proof latch, designed to endure 2,000 bend cycles. Its durability ensures that these patch cords are built to last, providing robust connectivity in even the most challenging conditions. A wide range of options, including 16 different lengths and 8 easy to identify colours ensures that you can find the perfect patch cord to suit your specific needs and match installation aesthetics. Backed by a lifetime warranty, the Kordz PRO SlimCat™ Patch Cords are the ultimate choice for professionals committed to excellence in every aspect of their installations.
- High-performance patch cords that are individually tested and exceed all ANSI/TIA 568.2-D Category 6 standards.
- Ultra-slim design with a 3.9mm cable diameter and small form-factor connector, ideal for space-conscious network installations.
- Robust durability ensured by a patented connector design with composite nylon snap-proof latch that can withstand an impressive 2,000+ bend cycles.
- Fully support IEEE802.3bt PoE++ 100W, making them suitable for power-hungry devices and applications.
- Choose from 16 different lengths (0.15m to 30.0m) and 8 easy to identify colours to match your specific installation needs and aesthetics.
- Reliable connectivity backed by Kordz’s product performance guarantee and a lifetime warranty.
| Performance Specifications | ||
| Applicable Standards: | ANSI/TIA-568.2-D Category 6 IEC 11801 Class E |
|
| Performance Standard: | ≤10m: ANSI/TIA-568.2-D Category 6 Patch Cord component, 1-250MHz ≥15m: ANSI/TIA-568.2-D Category 6 channel, 1-250MHz |
|
| Construction | ||
| Conductors: | Stranded 28 AWG Oxygen Free Copper | |
| Conductor Insulation: | Polyolefin | |
| Shielding: | Not applicable | |
| Cable Jacket Material: | UL CM-rated PVC composite | |
| Connector Material: | Nylon composite | |
| Contact Type: | 50μ” gold-plated phosphor bronze contacts | |
| Strain Relief: | Injection-moulded PVC | |
| Mechanical (at 20°C ± 5°C) |
||
| Cable Diameter: | 3.9mm/0.15in Ø | |
| Maximum Cable Pulling Tension: | 80 kgf/cm² | |
| Cable Bend Radius: | 11.7mm | 0.46″ | |
| Recommended Total Mounting Depth: | 27.7mm | 1.09″ | |
| Connector Mating Cycles (max.) | 1000 cycles | |
| Connector Latch bend cycles (max.): | 2000 cycles | |
| Operating Temperature Range | -20°C to 75°C |
