Description
- 2 channel Integrated Amplifier with 70W per Channel
- Built-in DAC/ Optical / Coaxial inputs
- Analog Mode to isolate all digital circuitry and tune to your exact sound
- MM Phono Equalizer Amp
- Bluetooth Connection for your favourite songs wireless
- Subwoofer out for more bass
- Headphone Jack output for isolated listening without large speakers
Custom install product – If you’re looking for this product to be installed in your home, our specialist installation team can help. Contact us online or give us a call to discuss your installation.
Designed for the aspiring music enthusiast, the Denon PMA-600NE is the superior choice for those who want to build their first 2-channel Hi-Fi system. The PMA-600NE allows for the most vivid and emotional reproduction of vinyl and hi-res audio with digital inputs and a built-in phono equaliser. Listen to your favourite music via Bluetooth as well for seamless streaming of nearly unlimited songs. From deep bass to detailed highs, enjoy your favourite high-resolution audio content with the 192kHz/24bit D/A converter. At 70 Watts (4ohm, 1kHz, THD: 0.7%) per channel, the PMA-600NE supplies enough power to drive your speakers for optimal sound. Connect the PMA-600NE to your favourite components with the two Optical and one Coaxial digital input. Powered by the Denon Advanced High Current (AHC) single-push-pull circuit power amplifier, the PMA-600NE provides exceptional sound quality that balances high power with delicate, musical details.
High Power 70W Integrated Amplifier
Power your loudspeakers with the Denon PMA-600NE integrated amplifier. Engineered with remarkable Denon amplifier technology, the PMA-600NE delivers 70 Watts of power-per-channel (4ohm, 1kHz, THD 0.7%). This integrated amplifier offers compatibility with the widest range of speaker types and impedances for operational stability.
Advanced High Current (AHC) Single-Push-Pull Circuit
Enjoy powerful sound with detailed, musical accuracy. The PMA-600NE incorporates AHC transistors with two-to-three times the electrical current supply capacity of conventional audio power transistors. The acclaimed Denon AHC single-push-pull circuit now allows for the discrete amplifier in the PMA-600NE, producing powerful sound with musical fidelity.
High-Grade Audio Components
Denon engineers carefully constructed the amplifier circuit within the PMA-600NE to secure a frequency response of up to 100 kHz during applied use. The volume circuit suppresses noise in the amplifier, achieving high sonic resolution. The PMA-600NE handles a wide, dynamic range of high-resolution audio sources with tone control and power throughout.
| Features | ||
| Channels: | 2 | |
| Digital in: USB-B / optical / coaxial / USB-A: | No / 2 / 1 / No | |
| Sample Rate digital In: | 192 kHz / 24-bit | |
| DAC Chip: | PCM5141 | |
| Bluetooth / aptX / NFC: | Yes / No / No | |
| Analogue Mode: | Yes | |
| Advanced HC-TR single push pull circuit: | Yes | |
| Wide range amplifier: | Yes | |
| High current dynamic power supply: | Yes | |
| Power amp discrete construction: | Yes | |
| Micro processor auto off: | Yes | |
| Balance / Bass / Treble / Loudness: | Yes / Yes / Yes / No | |
| Shottky diodes: | Yes | |
| Solid heat sinks: | Yes | |
| Source Direct: | Yes | |
| Inputs / Outputs | ||
| Audio Inputs: | 5 | |
| Digital in: USB-B / optical / coaxial / USB-A: | No / 2 / 1 / No | |
| Phono Input: MM / MC: | Yes / No | |
| Audio outputs: | 1 | |
| Pre-out / Main-in: | Subwoofer / No | |
| Gold-plated cinch: | Yes | |
| Number of terminals: | 2 | |
| Remote Control Bus in / out: | Yes | |
| HEOS Link compatibility: IR / IP: | Yes / No | |
| Headphone out: | Yes | |
| Audio Specifications | ||
| Output power 8 Ohm (20 Hz – 20 kHz, T.H.D. 0.07%): | 45W | |
| Output power 4 Ohm (1 kHz, T.H.D. 0.7%): | 70W | |
| Total Harmonic Distortion: | 0.02% | |
| Input Sensitivity: MM: | 2.5 mV / 47 kohm | |
| Signal to Noise Ratio: MM/MC: | 84 dB / No | |
| Input Sensitivity: High level: | 110 mV / 30 kohms | |
| Signal to Noise Ratio: High level: | 105dB | |
| Treble Control: | ± 8 dB at 10 kHz | |
| Bass Control: | ± 8 dB at 100 Hz | |
| General | : | |
| Metal Front Panel: | Yes | |
| Power Consumption in W: | 185 | |
| Standby Consumption in W: | 0.3 | |
| Auto Power Off: | Yes | |
| Remote Control: | RC-1234 | |
| System Remote Function: | Yes | |
| Maximum Dimensions (W x D x H) in mm: | 434 x 308 x 121 | |
| Weight in kg: | 6.8 | |
| Carton Maximum Dimensions (W x D x H) in mm: | 520 x 370 x 207 | |
| Carton Weight (inc. product) in kg: | 8.1 |
