Description
| Technical Information | ||
| Number of Power Amps: | 9 | |
| Power Output: | 105 watts per channel (8 ohm, 20Hz-20Khz, 0.08%, 2ch drive) 135 watts per channel (6 ohm, 1 khz, 0.7%, 2ch drive) 180 watts per channel (6 ohm, 1 kHz, 1%, 1ch drive) |
|
| General | ||
| System Remote Control: | RC-1253 | |
| Power Consumption: | 660W | |
| Power Consumption(No Sound): | 60W/100W | |
| Standby Consumption in W: | 0.1 | |
| CEC Standby Consumption in W: | 0.5 | |
| Maximum Dimensions Antenna:Horizontal (mm): | 434 x 389 x 167 | |
| Antenna:Horizontal (mm): | 434 x 389 x 236 | |
| w/o Antenna: (mm): | 434 x 379 x 167 | |
| Weight (kg): | 12.5 | |
| Video | ||
| HDMI In/Out: | 6/3 | |
| Multi-Room Video Out: Video, HDMI: | -,Yes | |
| Audio | ||
| Analogue In/Out | 6/- | |
| Phono (MM) In: | Yes | |
| Digital in: Optical/Coaxial | 2/2 | |
| Multi-Room Out: Analogue, Digital: | 1,- | |
| Multichannel Pre-Out | Yes (11.4) | |
| Subwoofer Out: | 4 (independent) | |
| Other | ||
| Compatible with Remote APP for smart phones: | Denon 2016 AVR Remote | |
| Auto Speaker Setup by Microphone: | Audyssey MultEQ XT32Dirac Live (upgrade) | |
| Front Display: | 1-Line FLD | |
| GUI Languages: | 9 |
