Blustream SP14CS 4K HDMI 2.0 1×4 Splitter
The Blustream SP14CS is a high-performance 4K HDMI 2.0 splitter designed to distribute a single HDMI source to four simultaneous displays. Supporting full 18Gbps bandwidth and HDCP 2.2 compliance, it delivers stunning 4K UHD video at 60Hz with 4:4:4 colour sampling.
Ideal for home cinema, commercial AV, retail displays, and multi-room installations, the SP14CS also features both digital (optical S/PDIF) and analogue stereo audio breakout, allowing flexible integration with external audio systems.
With intelligent video downscaling on each output, the splitter ensures compatibility with mixed-resolution displays — allowing 4K 60Hz 4:4:4 content to be shown at full resolution on compatible screens while automatically adjusting for displays that support lower resolutions.
Key Features
-
1x HDMI input distributed to 4x simultaneous HDMI outputs
-
HDMI 2.0 (18Gbps) with HDR support
-
Supports up to 4K UHD 60Hz 4:4:4
-
Individual output downscaling for mixed 4K and 1080p display setups
-
Compatible with resolutions from VGA–WUXGA and 480i–4K
-
Supports Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
-
Simultaneous HDMI audio breakout to analogue L/R and optical digital outputs
-
Advanced EDID management for reliable system integration
-
HDCP 2.2 compliant
SPECIFICATION
• Video Input Connectors: 1x HDMI Type A
• Video Output Connectors: 4x HDMI Type A
• EDID: 4-PIN DIP switch
• Smart Scale: 4-PIN DIP switch
• Audio Output Connectors: 1x Digital (Optical), 1x Analogue audio L/R (3.5mm stereo Jack)
• Dimensions (W x D x H): 203mm x 84mm x 23mm, without feet
• Shipping Weight: 0.8kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature : -4°F to 140°F (-20°C to 60°C)
• Power Supply: 5V/2A DC
